K0104
49338 liter heat-/coolable pressure tank, Aisi 316
€39,800.00
incl. VAT
€47,362.00
Price per piece, excl. VAT
2 pieces on stock
General Information
Manufacturer
Schleifenbaum & Weber
location
External warehouse
condition
used
Vessel
volume
49.338 liter
vacuum
1,0 bar
max. excess pressure
6,0 bar
specific weight of the medium
1.5 (to/m³)
lower bottom
torispherical bottom
upper bottom
torispherical bottom
construction
standing
stand type
legs
quantity legs
4 Piece
double jacket
double jacket
available
max. allowable working overpressure (dj)
6.0 bar
max. allowable working temperature (dj)
200 °C
Temperature control cylinder (dj)
half-coil
temperature control bottom (dj)
half-coil
Technical Characteristics
diameter inside
2.800 mm
diameter outside
3.100 mm
cylindrical height
7.483 mm
total height
10.000 mm
Wall thickness lower bottom
18 mm
wall thickness cylinder
14 mm
wall thickness of upper bottom
15 mm
Equipment
Technical documentation
drawing,various documents
manhole
in the cylinder, in the upper bottom (Ø 600)
nameplate
technical equipment
crane eyes
outlet
100 mm
latest application
chemistry
Material Composition
material in contact w/ medium
AISI316Ti 1.4571
material legs
mild steel
