8949
Alfa Laval 11.5 m² spiral heat exchanger; Aisi 316
€6,500.00
incl. VAT
€7,735.00
Price per piece, excl. VAT
3 pieces on stock
Unterlagen vorhanden
General Information
location
Bremen
condition
used
Other
Dents in the insulating jacket; 1 heat exchanger has an overall height that is approx. 230 mm higher due to a flanged connection
Heat exchangers
Technical documentation
drawing
exchange surface
11.5 m²
latest application
Pharmaceutical Chemistry
nameplate
insulation
available
material insulation jacket
aluminium
Shell Space
volume double jacket
226 liter
material of jacket
AISI316 (V4A) 1.4404
max. allowable working overpressure double jacket
4.2 bar
max. allowable working underpressure double jacket
1,0 bar
max. allowable working temperature (dj)
200 °C
Tube Space
volume pipe area
50 liter
material pipes
AISI316 (V4A) 1.4404
max. allowable working temperature in tube side
200 °C
max. allowable working overpressure in tube side
5,0 bar
Technical Characteristics
diameter outside
720 mm
diameter inside
540 mm
total height
2.200 mm
